General Information
- Model: FBR15-NQC3/FBR20-NQC3/FBR25-NQC3
- Lifting capacity: 1,500/2,000kg/2,500kg
- Maximum lifting height: 4,000mm
The Trust Horse Reach Truck is developed as an advanced warehouse material handling solution, delivering efficient and reliable performance for modern warehouse and intralogistics applications.
Featuring advanced ergonomic design, high-performance systems, and modern control technology, the Reach Truck provides excellent maneuverability, precise lifting, and stable operation. Its specialized design enables efficient operation in narrow aisles and high-level racking systems, while helping maximize available warehouse storage space.
The Trust Horse Reach Truck is an ideal solution for logistics warehouses, distribution centers, high-density storage facilities, high-level racking systems, and modern intralogistics operations, helping businesses improve productivity and overall warehouse efficiency.
Main Specification
|
Model |
FBR15-NQC3 |
FBR20-NQC3 |
FBR25-NQC3 |
|
|
Rated Load Capacity |
Q (kg) |
1500 |
2000 |
2500 |
|
Load Centre |
C (mm) |
500 |
500 |
500 |
|
Overall Length |
L1 (mm) |
2270 |
2505 |
2685 |
|
Overall Width |
B1 (mm) |
1090 |
1200 |
1200 |
|
Height to Safeguard |
H5 (mm) |
2250 |
2250 |
2250 |
|
Min. Turning Radius |
Wa (mm) |
1700 |
1750 |
1930 |
|
Wheelbase |
Y (mm) |
1470 |
1500 |
1680 |
|
Travel Speed (Full Load) |
km/h |
9.5 |
8.5 |
8.5 |
|
Travel Speed (No Load) |
km/h |
10.0 |
9.0 |
9.0 |
|
Max.Gradeability (Full Load) |
% |
10 |
10 |
10 |
|
Total Weight (Include Battery Box) |
Kg |
2450 |
2680 |
2780 |
|
Battery |
V/Ah |
48/375 |
48/450 |
48/450 |
