General Information
- Model: FB20/FB25
- Lifting capacity: 2,000kg-2,500kg
- Maximum lifting height: 6,000mm
The Trust Horse V Series Lithium Battery Forklift represents the next generation of electric forklifts, featuring a completely new design that combines advanced technology, outstanding performance, and exceptional durability.
Equipped with a high-performance lithium battery system, intelligent electronic controls, and full AC drive technology, the V Series delivers powerful performance, smooth operation, and excellent reliability for demanding material handling applications. With fast charging, extended operating hours, zero emissions, and minimal maintenance requirements, it provides an efficient and cost-effective alternative to traditional internal combustion forklifts.
Designed for warehouses, logistics centers, manufacturing facilities, and distribution operations, the Trust Horse V Series offers superior productivity, lower operating costs, and environmentally friendly performance, making it an ideal solution for modern material handling.
Main Specification
|
Model |
FB20 |
FB25 |
|
|
Rated Load Capacity |
Q(kg) |
2000 |
2500 |
|
Load Cener |
c(mm) |
500 |
500 |
|
Wheelbase |
y(mm) |
1620 |
1620 |
|
Total Weight |
kg |
3500/3550 |
3880/3930 |
|
Overhead Guard Height |
h6(mm) |
2245 |
2245 |
|
Length to Face of Fork (Without Fork) |
l2(mm) |
2415 |
2415 |
|
Overall Width |
b1(mm) |
1180 |
1180 |
|
Turning Radius (Outside) |
Wa(mm) |
2165 |
2165 |
|
Travel Speed (Full Load) |
km/h |
14/18 |
14/18 |
|
Travel Speed (No Load) |
km/h |
15/19 |
15/19 |
|
Max.Gradeability |
% |
15/19 |
15/19 |
|
Max.Gradeability (No Load) |
% |
15/20 |
15/20 |
|
Battery |
V/Ah |
76.8V230Ah 76.8V/304Ah |
76.8V230Ah 76.8V/304Ah |
